DS-200 Series Portable Colorimeter Dual Optical Path Whiteness Yellowness Test for Textile Paper Plastic
Repeatability accuracy dE*ab≤0.03
Contains UV
Three caliber switching is available
Built-in HD camera
Support Android, Apple, Hongmeng mobile APP
Technical Parameters
Product model | DS-200 | DS-210 | DS-220 |
Measurement structure* | D/8，SCI | ||
Measurement repeatability** | ΔE*ab≤ 0.03 | ||
Display accuracy | 0.01 | ||
Measuring aperture | |||
| Measurement index | Spectral reflectance,CIE-Lab,CIE-LCh,HunterLab,CIE-Luv,XYZ,Yxy,RGB,Chromatic Aberration(ΔE*ab,ΔE*cmc,ΔE*94,ΔE*00), Whiteness(ASTM E313-00,ASTM E313-73,CIE,ISO2470/R457,AATCC,Hunter,Taube Berger Stensby),Yellowness(ASTM D1925, ASTM E313-00,ASTM E313-73),Blackness(My,dM),Color fastness, Color fastness,Tint(ASTM E313-00), Colour densityCMYK(A,T,E,M),Isochromatic index Milm, Munsell, covering power, force (dye strength, coloring power) | ||
Light source condition | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83, TL84,ID50,ID65,LED-B1,LED-B2,LED-B3,LED-B4,LED-B5,LED-BH1,LED-RGB1,LED-V1,LED-V2 | ||
Lighting source | All-band equalizationLED light source | All-band equalizationLED light source +UV | |
Measurement and observation mode | Visual | Camera positioning | |
Calibrate | Manual calibration | Intelligent automatic calibration | |
Software support | Assurance of metrology | Ensure the first level of measurement | |
Field Angle | 2°，10° | ||
Integrating sphere diameter | 40mm | ||
Meet the standard | CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 | ||
Spectroscopic method | Nano integrated spectral device | ||
Inductor | Silicon photodiode array Double16 groups | ||
Wavelength interval | 10nm | ||
Wavelength range | 400-700nm | ||
Reflectance measurement range | 0-200% | ||
Reflectance resolution | 0.01% | ||
Measurement mode | Single measurement, average measurement（2~99 times） | ||
Measuring time | About1s | ||
Port | USB，Bluetooth | ||
Screen | IPS full color screen, 2.4 inches | ||
Battery capacity | Continuous measurement on a single charge8000 times， 3.7V/3000mAh | ||
Light source lifetime | 1 million times in 10 years | ||
Language | Simplified Chinese, English | ||
Store | Instrument: standard sample100 pieces, 10000 samples; APP mass storage | ||
* Diffuse illumination /8° direction reception, including specular reflected light
** The whiteboard is calibrated to measure 30 standard deviations at 5-second intervals
Functional model list
Model number | DS-200 | DS-210 | DS-220 |
Measurement condition | SCI | SCI | SCI |
Repeatability | ≤ 0.03 | ≤ 0.03 | ≤ 0.03 |
Caliber | Two | Four | Six |
AboutUV light source | × | × | √ |
Camera function | × | √ | √ |
| CellphoneAPP | √ | √ | √ |
PC software | √ | √ | √ |
Measurement scenario examples
|
|
| Colorimeter DS-200 measures paint color difference | Colorimeter DS-200 measures the color difference of textile samples |
 |  |
| Colorimeter DS-200 measures the whiteness value of tiles | Colorimeter DS-200 measures the color difference of packaging bags |
Shelf life: One-year warranty
