FS-20 Imaging hyperspectral camera

WeChat

copy Link

Facebook

The CHNSpec FS-20 Hyperspectral Camera is a next-generation spectral imaging system engineered for high-precision color measurement, material identification, and image analysis. Utilizing advanced push-broom technology, the FS-20 seamlessly integrates traditional 2D spatial imaging with 1D spectral data, capturing even the most minute spectral differences. Whether for meticulous laboratory research or high-speed industrial production lines, the FS-20 delivers unparalleled stability and precision.

Model	FS-20
Spectroscopic mode	Transmission grating light splitting
Image resolution	1920*1920
Dynamic range	12 bits
Imaging speed	＜15 seconds
Number of spectral channels	600
Spectral range	400-700nm
Spectral FWHM	2.5nm
Slit width	25um
Transmission efficiency	60%
Stray light level	0.5%
Pixel size	5.86um*5.86um
Detector type	CMOS
Dimensions of sensor imaging surface	11.3*7.1mm
Standard lens focal length	25mm
Minimum working distance	100mm
Field angle	25°
Minimum exposure time	34us
Maximum exposure time	10s
Signal-to-noise ratio	600/1
Data interface	USB3.0
Camera lens interface	C
Parts	USB3.0 Transmission line
Imaging function	ROI function Can realize single regional ROI
Auxiliary imaging function	Auxiliary viewfinder Monitoring the shooting area
Power supply mode	Built in battery power
Host size*	255mm138mm107mm
Weight**	＜2.8kg
