TH-06 Haze Meter

WeChat

copy Link

Facebook

The CHNSpec TH-06 is a high-precision handheld colorimeter featuring an ergonomic design for easy operation. It rapidly measures color difference data of solids, powders, and liquids. Widely used in paint, textile, and plastic industries for on-site color inspection and incoming material checks, ensuring color consistency.

DetailSupports

1. Product Features

Standard 0/d Optical Structure: More accurate test data
Measurement parameters: Haze, Transmittance under ASTM and ISO standards
Long Life: Light source lasts 5 years or 5 million times
Precise Measurement: Resolution of 0.01, repeatability of 0.08
Massive Storage: Can store 20,000 data sets
Touchscreen Operation: Capacitive touchscreen for smoother operation
Clear Display: 7-inch IPS full-angle screen
Data Management: Comes with PC software that supports data export and report printing

2. Technical Parameters

Product Model	TH-06
Light Source	CIE-A、CIE-C、CIE-D65
Standards Compliance	ASTM D1003/D1044，ISO13468/ISO14782，JIS K 7105，JIS K 7361，JIS K 7136，GB/T 2410-08
Measurement Parameters	Haze, Transmittance under ASTM and ISO standards
Spectral Response	CIE Spectral Function Y/V(λ)
Optical Path Structure	0/d
Measurement Aperture	21mm
Measurement Range	0-100%
Resolution	0.01%
Repeatability	0.08
Sample Size	Thickness ≤ 145mm
Display	7-inch IPS full-angle LCD
Touch	Capacitive Touchscreen
Data Storage	20,000 values
Light Source Lifetime	5 years or 5 million times
Interface	USB Interface
Power Supply	DC 12V/3A
Working Temperature	5℃–40℃, relative humidity ≤80% (at 35℃), no condensation
Storage Temperature	-20℃–45℃, relative humidity ≤80% (at 35℃), no condensation
Dimensions	Length × Width × Height: 310mm × 215mm × 540mm
Weight	6kg
Standard Accessories	PC management software (HAZE QC)
Optional Accessories	Measurement fixtures, haze standard plates, custom aperture plates
