TH-07 Haze Meter
The TH-07 Haze Meter from Caipu Technology is a high-precision instrument designed for measuring haze and light transmittance of transparent/translucent materials (e.g., plastics, glass, films).
Featuring a user-friendly interface and fast testing speed, it delivers accurate data compliant with international standards. Compact in size, it suits both laboratory analysis and on-site quality control, helping industries like packaging, electronics, and automotive ensure material optical performance efficiently.
1.Product Features
Standard 0/d Optical Structure: More accurate test data
Measurement Aperture: Supports dual apertures of 21mm and 7mm
Measurement parameters: Haze, Transmittance under ASTM and ISO standards
Long Life: Light source lasts 5 years or 5 million times
Precise Measurement: Resolution of 0.01, repeatability of 0.05
Massive Storage: Can store 20,000 data sets
Clear Display: 7-inch IPS full-angle screen
Data Management: Equipped with PC software, supports data export and report printing
2.Technical Parameters
Product Model | TH-07 |
Light Source | CIE-A、CIE-C、CIE-D65 |
Standards Compliance | ASTM D1003/D1044，ISO13468/ISO14782，JIS K 7105，JIS K 7361，JIS K 7136，GB/T 2410-08 |
Standards Compliance | Haze, Transmittance under ASTM and ISO standards |
Spectral Response | CIE Spectral Function Y/V(λ) |
Optical Path Structure | 0/d |
Measurement Aperture | 21mm，7mm |
Measurement Range | 0-100% |
Resolution | 0.01% |
Repeatability | 0.05 |
Sample Size | Thickness≤145mm |
Display | 7-inch IPS full-angle LCD |
Touch | Capacitive Touchscreen |
Data Storage | 20,000 values |
Light Source Lifetime | 5 years or 5 million times |
Interface | USB Interface |
Power Supply | DC 12V/3A |
Working Temperature | 5~40°C, relative humidity ≤80% (at 35°C), no condensation |
Storage Temperature | -20~45°C, relative humidity ≤80% (at 35°C), no condensation |
Dimensions | Length x Width x Height: 310mm x 215mm x 540mm |
Weight | 6kg |
Standard Accessories | PC management software (HAZE QC) |
Optional Accessories | Measurement fixtures, haze standard plates, custom aperture plates |
